Monarch EDGE S1 Simultaneous single channel encoder and decoder for remote production
Product Highlights:
- Multi-Stream H.264 Video Encoder/Decoder
- Record to Local Drives via USB
- SRT, RTSP, UDP Streaming Support
- Genlock, CC, HDR, VITC Support
- Tally and Talkback Support
- Genlock, CC, HDR, VITC Support
- Supports 16 x Audio Channels per Input
- 3G-SDI and Dual 25GB SFP Inputs/Outputs
Overview:
Matrox Monarch EDGE S1 Simultaneous Encode/Decode Appliance. Simultaneously receive, stream, and record video using SDI and IP sources and destinations with the Monarch EDGE S1 Simultaneous Encode/Decode Appliance from Matrox. The Monarch EDGE S1 provides simultaneous encoding and decoding services for streaming and return feeds for your broadcast crew. This functionality makes it suitable for broadcast and other professional workflows that require streaming and recording of content, such as houses of worship and universities. The 1 RU, half-rack design helps it easily fit into your broadcast truck or studio.
Elevate your remote production and live contribution workflows with the Monarch EDGE S1, our professional, single-channel encoder and decoder that provides return feeds to multi-camera production crews in real-time. Transmit high-resolution, low-latency streams of HDR 4:2:2 10-bit video carrying ancillary data (SCTE and ANC) over SRT and MPEG-2TS
.
Reliable return feeds for remote production
Monarch EDGE S1 delivers high-quality, low-latency return feeds that keep on-site staff and camera operators perfectly in-sync with the live program. As a simultaneous encoder and decoder, the S1 efficiently sends program feeds from the studio back to the remote venue, giving production teams real-time visibility and the confidence they need to produce high-quality remote broadcasts.
Big productions, small footprint
Bringing remote guests and talent together from separate locations into live productions has never been easier. With simultaneous encode/decode capability, Monarch EDGE S1 provides remote participants with a single encoding contribution feed while decoding a return feed. This feature, combined with its low latency performance over public internet, allows remote participants to easily interact with the live show and panel in real-time.
Built for high quality 10-bit H.264 encoding
The optimized H.264 engine powering Monarch EDGE S1 keeps bitrates exceptionally low without sacrificing quality. The input can be streamed at resolutions up to 1080p60. Furthermore, multiple processes can be performed on the input via a powerful scaling and de-interlacing engine. This enables the input to be streamed at multiple resolutions and bitrates simultaneously, making it ideal for remote monitoring.
Exceptionally low latency
With glass-to-glass latencies as low as 100 ms between Monarch EDGE S1 devices, staff at the production venue can benefit from viewing return feeds of the live broadcast in near-real time. Furthermore, when a live production has remote guest requirements, these ultra-low latencies can facilitate near-real time interactions between speakers.
Flexible protocols, secure streaming
Monarch EDGE S1 supports multiple streaming protocols, such as MPEG-2 TS, RTSP, and SRT, to adapt to a wide range of environments. On closed networks, MPEG-2 TS will deliver the lowest latency. For cloud-based destinations, or when the network is congested, SRT may be more appropriate to reduce latency on open networks. SRT streams can also be encrypted if security is a concern.
Ancillary data for automation and viewer experience
Monarch EDGE supports contribution workflows by sending and receiving ancillary data, including closed captioning and SCTE messaging. Easily integrate into automated workflows for playout and ad insertion and transmit closed captions to enhance audience engagement. Monarch EDGE improves operational efficiency and strengthens the overall viewer experience, all with the highest video quality, making it a trusted choice for broadcasters.
Robust and practical design
A single Monarch EDGE S1 sends the contribution feed to the studio and receives the program return, delivering low-latency, two-way communication for seamless remote contribution.
